%ACD_LINE%

1

The index of the registration (line) used to support BroadSoft server-based ACD.; Line 1 – 34

%ACD_SIGNALING%

0

0 (default) – The ‘SIP-B’ signaling is supported. (This is the older ACD functionality.); 1 – The feature synchronization signaling is supported. (This is the new ACD functionality.)

%ACD_SIGNIN_STATE%

1

The state that the user must attain on singing in.; If set to 1 or Null, the user’s state will be set to Available.; If set to 0, the user’s state will be set to Unavailable.

%ACOUSTIC_FENCING_PHONE_MENU%

0

%ACOUSTIC_HANDSET_ENABLE%

1

%ACOUSTIC_HANDSET_ENABLE%

1

%ACOUSTIC_HEADSET_ENABLE%

1

voice.aes.hs.enable; 1 (default) – Enables the handset AES function.; 0 – Disables the handset AES function.

%ACOUSTIC_HEADSET_ENABLE%

1

voice.aes.hs.enable; 1 (default) – Enables the handset AES function.; 0 – Disables the handset AES function.

%ACOUSTIC_HEADSET_ENABLE%

1

%ACOUSTIC_HEADSET_ENABLE%

1

%ACOUSTIC_NONSTATIONARY_THRESH%

8

%ACOUSTIC_NONSTATIONARY_THRESH%

8

%ACOUSTIC_STATIONARY_THRESH%

8

%ACOUSTIC_STATIONARY_THRESH%

8

%ADVANCEDMISSEDCALLS_ENABLED%

1

Use this parameter to improve call handling.; 1 (default) – Shared lines can correctly count missed calls.; 0 – Shared lines may not correctly count missed calls.

%AUDIBLE_RINGER%

chassis

Set where alerts and sound effects play out.; chassis (default) —Alerts and sound effects play out through the phone’s speakerphone.; headset (if connected); handset active —Alerts play from the destination that is currently in use. For example, if a user is in a call on the handset, a new incoming call rings on the handset.

%AUTO_ANSWER%

0

This parameter cannot be used with VVX 101, 150, or 201 phones.; 0 (default) – Disable auto-answer for SIP calls.; 1 – Enable auto-answer for SIP calls.

%AUTO_ANSWER_MUTEMIC%

1

1 (default) – The microphone is initially muted after a call is auto-answered.; 0 – The microphone is active immediately after a call is auto-answered.;

%CALL_WAITING_ENABLE%

1

Enable or disable call waiting.; 1 (default) – The phone alerts you to an incoming call while you are in an active call. If 1, and you end the active call during a second incoming call, you are alerted to the second incoming call.; 0 – You are not alerted to incoming calls while in an active call. The incoming call is treated as if you did not answer it.

%CALL_WAITING_RING%

beep

Specifies the ringtone of incoming calls when another call is active. If no value is set, the default value is used.; beep (default) – A beep tone plays through the selected audio output mode on the active call.; ring – The configured ringtone plays on the speaker.; silent – No ringtone.

%CC_CODEx%

String limit for the code value that displays in the list for unavailable reason X. There is no default for this parameter.; 1 to 255 characters

%CC_CODEx_REASON%

String limit for the unavailable reason description for unavailable reason X. There is no default for this parameter.; 1 to 255 characters

%CDP%

1

Determine if the phone attempts to determine its VLAN ID and negotiate power through CDP.; 0 – Disabled; 1 – Enabled

%CFNA_NO_RINGS%

0

The number of seconds the phone should ring for before the call is forwarded because of no answer. The maximum value accepted by some call servers is 20.; 0 – (default); 1 to 65535

%CLI_PREFERENCE%

Specify the priority order for the sources of caller ID information. The headers can be in any order.; Null (default) – Caller ID information comes from P-Asserted-Identity, Remote-Party-ID, and From in that order.; From,P-Asserted-Identity, Remote-Party-ID; P-Asserted-Identity,From,Remote-Party-ID; Supported Headers Default Order: P-Asserted-Identity,Remote-Party-ID,From

%CONFERENCE_HOLD_ENABLED%

1

0 (default) – The host cannot place parties on hold.; 1 – During a conference call, the host can place all parties or only the host on hold.

%DATE_FORMAT%

D,dM

The phone displays day and date. The field may contain 0, 1, or 2 commas which can occur only between characters and only one at a time.; For example: D,dM = Thursday, 3 July or Md,D = July 3, Thursday.; "D,dM" (default); String

%DATE_LONG_FORMAT%

0

1 (default) – Displays the day and month in long format (Friday/November).; 0 – Displays the day and month in abbreviated format (Fri/Nov).

%DAYLIGHT_FIXED_DAY_ENABLE%

0

0 (Default) – Month , date , and dayOfWeek are used in the DST calculation.; 1 – Only month and date are used in the DST calculation.

%DAYLIGHT_SAVINGS_ENABLE%

1

Enable or disable Daylight Savings Time rules to the displayed time.; 1 (Default) – Enabled; 0 – Disabled;

%DAYLIGHT_START_DATE%

8

Start date for daylight savings time. Range is 1 to 31.; 8 (Default) – Second occurrence in the month after DST starts.; 0 – If fixedDayEnable is set to 0, this value specifies the occurrence of dayOfWeek when DST should start.; 1 – If fixedDayEnable is set to 1, this value is the day of the month to start DST.; 15 – Third occurrence.; 22 – Fourth occurrence.; Example: If value is set to 15, DST starts on the third dayOfWeek of the month.

%DAYLIGHT_START_DAYOFWEEK%

1

Specifies the day of the week to start DST. This parameter is not used if fixedDayEnable is set to 1.; 1 (Default) – Sunday; 1-7 where the integer entered corresponds to a day of the week. For example, 1 = Sunday, 2 = Monday, and so on to 7 = Saturday.

%DAYLIGHT_START_LASTINMONTH%

0

0 (Default); 1 – DST starts on the last dayOfWeek of the month and the start.date is ignored.; Note: This parameter is not used if fixedDayEnable is set to 1.

%DAYLIGHT_START_MONTH%

3

Specifies the month to start DST.; 3 (Default) – March; 1-12 where the integer entered corresponds to a month of the year. For example, 1 = January, 2 = February and so on to 12 = December.;

%DAYLIGHT_START_TIME%

2

Specifies the time of day to start DST in 24-hour clock format. Range is 0 to 23.; 2 (Default) – 2 a.m.; 0 – 23 where the integer entered corresponds to the hour on in a 24 span. For example, 0 = 12 AM, 1 = 1 AM, and so on to 23 = 11 PM.

%DAYLIGHT_STOP_DATE%

1

Specifies the stop date for daylight savings time. Range is 1 to 31.; 1 (Default) – If fixedDayEnable is set to 1, the value of this parameter is the day of the month to stop DST. Set 1 for the first occurrence in the month.; 0 – If fixedDayEnable is set to 0, this value specifies the dayOfWeek when DST should stop.; 8 – Second occurrence.; 15 – Third occurrence.; 22 – Fourth occurrence.; Example: If set to 22, DST stops on the fourth dayOfWeek in the month.

%DAYLIGHT_STOP_DAYOFWEEK%

1

Day of the week to stop DST.; 1 (default) – Sunday; 1-7 where the integer entered corresponds to a day of the week. For example, 1 = Sunday, 2 = Monday, and so on to 7 = Saturday.; Note: Parameter is not used if fixedDayEnable is set to 1.

%DAYLIGHT_STOP_LASTINMONTH%

0

1 – DST stops on the last dayOfWeek of the month and the stop.date is ignored).; Parameter is not used if fixedDayEnable is set to 1.

%DAYLIGHT_STOP_MONTH%

11

Specifies the month to stop DST. Range is 1 to 12.; 11 (Default) – November; 1-12 where the integer entered corresponds to a month of the year. For example, 1 = January, 2 = February and so on to 12 = Decembe

%DAYLIGHT_STOP_TIME%

2

Specifies the time of day to stop DST in 24-hour clock format. Range is 0 to 23.; 2 (Default) – 2 a.m.; 0 – 23 where the integer entered corresponds to the hour on in a 24 span. For example, 0 = 12 AM, 1 = 1 AM, and so on to 23 = 11 PM.

%DEVICE_ACCESS_PWD%

(contact support)

Set the password for the phone to log in to the provisioning server, which may not be required.; If you modify this parameter, the phone reprovisions. The phone may also reboot if the configuration on the provisioning server has changed.; String

%DEVICE_LANGUAGE%

lcl.ml.lang; Null (default) – Sets the phone language to US English.; String – Sets the phone language specified in the lcl.ml.lang.menu.x.label parameter.

%DEVICE_THEME%

Classic

Choose the user interface color scheme and icons that displays on the phone.; Classic (default); Modern (only on 501 and 601); BroadSoft;

%DEVICE_THEME_SET%

0

0 (default) – The phone does not apply the user interface theme specified in the device.theme parameter, and the default theme displays after a reboot.; 1 – The phone applies the theme specified in the device.theme parameter, and the selected theme displays after a reboot.

%DIAL_PLAN%

0.T|#xx|*xx.T|[2-8]xxT|[2-8]xxxT|1x.T|9x.T|[123456789]xxxxx.T|0[123456789]xxxxxxxx.T|00x.T|118xxxT|911

Specify the digit map used for the dial plan using a string compatible with the digit map feature of MGCP described in 2.1.5 of RFC 3435. This parameter enables the phone to automatically initiate calls to numbers that match a digit map pattern.; Note: The default value varies depending on the setting for the device.baseProfile setting.; Generic (default) –; [2-9]11|0T|+011xxx.T|0[2-9]xxxxxxxxx|+1[2-9]xxxxxxxx|[2-9]xxxxxxxxx|[2-9]xxxT; The string is limited to 2560 bytes and 100 segments of 64 bytes, and the following characters are allowed in the digit map.; A comma (,), which turns dial tone back on.; A plus sign (+) is allowed as a valid digit.; The extension letter ‘R’ indicates replaced string.; The extension letter ‘Pn’ indicates precedence, where ‘n’ range is 1-9.; 1 – Low precedence; 9 – High precedence

%DIAL_PLAN_TIMEOUT%

4|4|4|4|4|4|4|4|4|4|4|4

Specify a timeout in seconds for each segment of the digit map using a string of positive integers separated by a vertical bar ( | ). After a user presses a key, the phone waits this many seconds before matching the digits to a dial plan and dialing the call.; (Default) 3 | 3 | 3 | 3 | 3| 3; If there are more digit maps than timeout values, the default value 3 is used. If there are more timeout values than digit maps, the extra timeout values are ignored.

%DIR_AUTH_TYPE%

0

1 (default) – Uses BroadSoft XSP credentials.; 0 – Uses SIP credentials from dir.broadsoft.regMap.

%DIR_AUTH_TYPE%

0

If this parameter is disabled, the phones use standard SIP credentials to authenticate.; 1 (default) – Use this value, if phone lines are registered with a server running BroadWorks R19 or earlier.; 0 – Set to 0, if phone lines are registered with a server running BroadWorks R19 SP1 or later.

%DIRECTORY_REG%

1

Specify the registration line credentials you want to use for BroadSoft R20 Server or later to retrieve directory information from the BroadSoft UC-One directory when dir.broadsoft.useXspCredentials =0.; 1 (default); 0 – Const_NumLineReg;

%DIRECTORY_SERVER%

US: https://xsp.14ip.net; EU: https://eu-xsp.14ip.net

XSP address

%DIRECTORY_SHOW_DEFAULT%

1

0 (default) – No contacts are displayed when the search box field is empty.; 1 – Enables the user to view the initial list of contacts for an empty search box

%DISABLE_REDIAL_SOFTKEY%

0

Enable to display the Redial softkey. The parameter feature.enhancedFeatureKeys.enabled must be set to 1 first to configure this feature, and the parameter efk.softkey.alignleft must be set to 1 to move enabled softkeys into the positions of disabled softkeys.; 1 – Enabled; 0 (default) – Disabled

%DND_KEY%

1

1(default) – Enable Do Not Disturb (DND).; 0 – Disable Do Not Disturb (DND).

%DTMF_CHASSIS_MASKING%

0

0 (default) – DTMF tones play through the speakerphone in handsfree mode.; 1 – Set to 1 only if tone.dtmf.viaRtp is set to 0. DTMF tones are substituted with non-DTMF pacifier tones when dialing in handsfree mode to prevent tones from broadcasting to surrounding telephony devices or inadvertently transmitted in-band due to local acoustic echo.

%DTMF_CONTROL%

1

Specify if the phone uses RFC 2833 to encode DTMF tones.; 1 (default) – The phone indicates a preference for encoding DTMF through RFC2833 format in its Session Description Protocol (SDP) offers by showing support for the phone-event payload type. This doesn’t affect SDP answers and always honor the DTMF format present in the offer.; 0 – The phone doesn’t offer dynamic payload for RFC2833 phone-event.

%DTMF_LEVEL%

-15

The level of the high frequency component of the DTMF digit measured in dBm0; the low frequency tone is two dB lower.; -15; -33 to 3

%DTMF_VIA_RTP%

1

1 (default) – Encode DTMF in the active RTP stream. Otherwise, DTMF may be encoded within the signaling protocol only when the protocol offers the option.; 0 ‒ If you set this parameter to 0, you must set tone.dtmf.chassis.masking to 1.

%DTMFPAYLOAD%

127

Specify the phone-event payload encoding in the dynamic range to be used in SDP offers.; Generic (default) -127; 96 to 127

%EFK_ALIGN_LEFT%

1

Enable to display the Redial softkey. The parameter feature.enhancedFeatureKeys.enabled must be set to 1 first to configure this feature, and the parameter efk.softkey.alignleft must be set to 1 to move enabled softkeys into the positions of disabled softkeys.; 1 – Enabled; 0 (default) – Disabled

%EFK_PROMPTx_DIGITMATCHING%

none

%EFK_PROMPTx_FEEDBACK%

The user input feedback method.; visible (default) – The text is visible.; masked – The text displays as asterisk characters (*). You can use this to mask password fields.; If this parameter has an invalid value it and all dependent parameters are invalid.

%EFK_PROMPTx_LABEL%

The prompt text on the user prompt screen.; Null (default) – No prompt displays.; String; If the label does not fit on the screen, the label shortens and ‘…’ appends.

%EFK_PROMPTx_TYPE%

The type of characters entered by the user.; text (default) – The phone interprets characters as letters.; numeric – The phone interprets characters as numbers.; If Null, numeric is used. If this parameter has an invalid value, this prompt, and all parameters depending on this prompt, are invalid.; Note: A mix of numeric and text is not supported.

%EFK_x_NAME%

The text string used as a label on any user text entry screens during EFK operation.; Null (default) – Uses the Null string.; String (maximum of 64 characters); If the label does not fit on the screen, the text shortens and appends with ‘…’.

%EFK_x_NAME%

The unique identifier used by the speed dial configuration to reference the enhanced feature key entry. Cannot start with a digit. Note that this parameter must have a value, it cannot be Null.; expanded_macro (default); String (maximum of 64 characters);

%EFK_x_STRING%

The action string contains a macro definition of the action that the feature key performs.; Null (default); String (maximum of 64 characters); If you enable EFK, this parameter must have a value (it cannot be Null).;

%EFK_x_TYPE%

Defines the SIP method.; Invite (default) – Performs the required action using the SIP INVITE method.; Null – default of INVITE is used.; This parameter is included for backwards compatibility. Do not use if possible. If efk.x.action.string contains types, this parameter is ignored.

%ENABLE_ACD%

0

0 (default) – Disables the ACD agent available/unavailable feature.; 1 – Enables the ACD agent available/unavailable feature.

%ENABLE_ACD%

0

0 (default) – Disables the ACD login/logout feature.; 1 – Enables the ACD login/logout feature.

%ENABLE_ANONYMOUS_REJ%

0

0 (default) – Does not display the Anonymous Call Rejection menu to users.; 1 – Displays the Anonymous Call Rejection menu and the user can turn the feature on or off from the phone.

%ENABLE_ANSWERONLOCK%

1

1 (default) – Users can answer any incoming call without needing to unlock the phone.; 0 – Users must unlock the phone before answering an incoming call.

%ENABLE_BCM_SOFTKEY%

1

Displays the Hold and Transfer softkeys.; 1 (default) – Enabled; 0 – Disabled

%ENABLE_BLUETOOTH%

1

For high security environments.; 1 (default) – Enable Bluetooth and the Bluetooth phone screen icon.; 0 – Disable Bluetooth and the Bluetooth phone screen icon.

%ENABLE_BLUETOOTH%

1

0 – The Bluetooth radio transmitter/receiver is off.; 1 (default) – The Bluetooth radio is on. You must turn on the Bluetooth radio to allow devices to connect over Bluetooth.

%ENABLE_BUDDIES_SOFTKEY%

0

softkey.feature.buddies; Enable to display the Buddies softkey.; 1 (default) – Enabled; 0 – Disabled

%ENABLE_BW_ANYWHERE%

0

0 (default) – Disables and does not display the BroadWorks Anywhere feature menu on the phone.; 1 – Enables the BroadWorks Anywhere feature menu on the phone.

%ENABLE_CALL_LIST%

1

1 (default) – Allows you to enable the missed, placed, and received call lists on all phone menus including the Home screen and dialpad.; 0 – Disables all call lists.

%ENABLE_CALL_LOGS%

Disabled

Disabled (default) – Disable the BroadSoft server call logs feature.; Basic – Enable the BroadSoft server call logs feature.

%ENABLE_CALLERS_SOFTKEY%

0

Enable to display the Callers softkey for all platforms.; 1 – Enabled; 0 (default) – Disabled

%ENABLE_CALLPARK%

0

0 (default) – Disables the call park and call retrieve features.; 1 – Enables the call park and call retrieve features.

%ENABLE_CC_CODES%

0

1 – To turn Premium Feature Synchronized ACD on; 0 – To turn Premium Feature Synchronized ACD off

%ENABLE_CC_CODES%

0

0 (default) – Disable the status event threshold capability.; 1 – Enable the status event threshold capability to display at the top of the phone screen.

%ENABLE_CC_CODES%

0

X can be any number from 1 to 100. This number defines the order in which the reason is listed, from 1 to 100.; 0 – Disabled; 1 (default) – Enabled

%ENABLE_CC_INFORMATION%

0

1 (default) – The phone displays a full-screen popup showing call information details. The popup closes after 40 seconds or you can press the Exit button to close it and return to the active call screen. You can set how long the popup displays using the parameter up.idleTimeout.; 0 – The phone uses the active call screen and ACD call information is not available.

%ENABLE_CLID_BLOCK%

0

0 (default) – Disables and does not display the Line ID Blocking feature menu on the phone.; 1 – Enables the Line ID Blocking feature menu on the phone.;

%ENABLE_CLOCK%

1

Specifies whether or not the date and time are shown on the idle display.; 1 (Default) – Date and time are shown.; 0 – Date and time are hidden.

%ENABLE_DATETOP%

1

1 – Displays the date above time.; 0 (default) – Displays the time above date.

%ENABLE_DIRECTORIES_SOFTKEY%

1

Enable to display the Directories (Dir) softkey.; 1 (default) – Enabled; 0 – Disabled

%ENABLE_DISP_CODES%

0

1- To turn Feature Synchronized ACD Control URI on; 0 – To turn Feature Synchronized ACD Control URI off

%ENABLE_DND_SOFTKEY%

1

Enable or disable the Don’t Disturb (DND) softkey.; 1 (default) – Enabled; 0 – Disabled

%ENABLE_ECP%

0

0 (default) – To disable the BroadWorks Enhanced Call Park feature.; 1 – To enable the BroadWorks Enhanced Call Park feature.

%ENABLE_ECP_AUDIO_NOTIFICATION%

0

0 (default) – Disables the audio notifications for parked calls on private and shared lines.; 1 – Enables the audio notifications for parked calls on private and shared lines.

%ENABLE_EFK%

0

0 (default) – Does not allow configuring EFK as a line key.; 1 – Allows configuring EFK as a line key.

%ENABLE_EFK%

0 (default) – Disables the key x.; Null – Disables the key x.; 1 – Enables the key x.;

%ENABLE_EFK_PROMPTx%

0

This parameter must have a value. It cannot be Null.; 0 (default) – Disables the key.; 1 – Enabled the key.; If a macro attempts to use a prompt that is disabled or invalid, the macro execution fails.;

%ENABLE_ENDCALL_SOFTKEY%

1

Displays the End Call softkey.; 1 (default) – Enabled; 0 – Disabled

%ENABLE_EXEC_ASSISTANT%

0

0 (default) – Disables the BroadSoft Executive-Assistant feature.; 1 – Enables the BroadSoft Executive-Assistant feature

%ENABLE_FLK%

0

Enable to specify at least two calls per line key.; 0 (default) – Disabled; 1 – Enabled

%ENABLE_FORWARD%

1

1(default) – Enable call forwarding.; 0 – Disable call forwarding.;

%ENABLE_FORWARD_SOFTKEY%

1

Enable to display the Forward softkey.; 1 (default) – Enabled; 0 – Disabled

%ENABLE_GCP%

0

"Enable to display the Group call park softkey.; 1 (default) – Enabled; 0 – Disabled"

%ENABLE_GCP%

0

"""Enable to display the Group call park softkey.; 1 (default) – Enabled; 0 – Disabled"""

%ENABLE_GUI%

1

1 (default) – The web server is enabled.; 0 – The web server is disabled.

%ENABLE_GUI_BANNER%

0

Enable the security banner feature.

%ENABLE_GUI_BANNER_MESSAGE%

0

Configure the message to display on the security banner. Enter up to 2000 characters.

%ENABLE_GUI_LOCKOUT%

1

Enable the Guide Lockout

%ENABLE_GUI_LOCKOUT_DURATION%

60

The GUI lockout duration in seconds

%ENABLE_INTERCOM_SOFTKEY%

0

1 (default) – Enables the Intercom soft key.; 0 – Disables the Intercom soft key.

%ENABLE_JOIN_SOFTKEY%

0

Enable to display the Join softkey.; 1 (default) – Enabled; 0 – Disabled

%ENABLE_LINEVIEWCALL_STATUS%

0

0 (default) – In an active call, the active call screen displays. Any incoming or outgoing call triggers the display of the active call screen.; 1 – During an incoming call and in an active call, the line view displays and call details display on the status ribbon.

%ENABLE_LOCAL_DIRECTORY%

1

0 – The local contact directory is disabled.; 1 (default) – The local contact directory is enabled.

%ENABLE_MISSED_CALL_LIST%

1

0 (Default) – The missed call list is disabled.; 1 – The missed call list is enabled.; To enable the missed, placed, or received call lists, feature.callList.enabled must be enabled.

%ENABLE_MISSED_CALLS%

1

0 – The missed call counter doesn’t update regardless of how you configure call.serverMissedCalls.x.enabled or the server. The missed call list doesn’t display in the phone menu.; If call.missedCallTracking.x.enabled="1" and call.serverMissedCalls.x.enabled="0", then the number of missed calls increments regardless of how you configure the server.; If call.missedCallTracking.x.enabled="1" and call.serverMissedCalls.x.enabled="1", then the handling of missed calls depends on how you configure the server.;

%ENABLE_MWI_x%

1

1 (default) – The LED flashes as long as the phone has new unread voicemail messages for any line.; 0 – Red MWI LED doesn’t flash when there are new unread messages for the selected line.; x is an integer referring to the registration indexed by reg.x.

%ENABLE_NEWCALL_SOFTKEY%

0

Enable to display the New Call softkey.; 1 (default) – Enabled; 0 – Disabled

%ENABLE_PHONELOCK%

0

0 (default) – The phone lock feature is disabled; 1 – The phone lock feature is enable

%ENABLE_PHONELOCKSTATE%

0

0 (default) – The phone is unlocked.; 1 – The phone is locked.;

%ENABLE_PICKUP_SOFTKEY%

1

"Enable to display the Pickup softkey.; 1 (default) – Enabled; 0 – Disabled"

%ENABLE_PLACED_CALL_LIST%

1

0 (Default) – The placed call list is disabled.; 1 – The placed call list is enabled.; To enable the missed, placed, or received call lists, feature.callList.enabled must be enabled.

%ENABLE_POWERUPUNLOCKED%

0

Overrides the phoneLock.lockState parameter.; 0 (default) – The phone retains the value in phoneLock.lockState parameter.; 1 – You can restart, reboot, or power cycle the phone to override the value for phoneLock.lockState in the MAC-phone.cfg and start the phone in an unlocked state.; You can then lock or unlock the phone locally. Poly recommends that you do not leave this parameter enabled

%ENABLE_PRESENCE%

0

0 (default) – Disable the presence feature—including buddy managements and user status.; 1 – Enable the presence feature with the buddy and status options.

%ENABLE_QML%

0

0 (default) – Disable the QML viewer on the phone. Note that the UC-One directory user interface uses QML as the user interface framework and the viewer is used to load the QML applications.; 1 – Enable the QML viewer on phone.

%ENABLE_RECEIVED_CALL_LIST%

1

0 (Default) – The received call list is disabled.; 1 – The received call list is enabled.; To enable the missed, placed, or received call lists, feature.callList.enabled must be enabled.

%ENABLE_REMOTE_OFFICE%

0

0 (default) – Disables the Remote Office feature menu on the phone.; 1 – Enables and displays the Remote Office feature menu on the phone.

%ENABLE_SCREEN_ALERT%

0

1 (default) – The normal or automatic call appearance is spontaneously presented to the attendant when calls are alerting on a monitored resource (and a ring tone is played).; 0 – The call appearance is not spontaneously presented to the attendant. The information displayed after a press and hold of a resource’s line key is unchanged by this parameter. Note that the values of these call appearance parameters depend on the values applied to attendant.resourceList.x.type .; When this parameter is set to 0, the ringtone ‘Ring Splash’ does not play when attendant.ringType=ringer14 .

%ENABLE_SERVER_CWAIT%

0

0 (default) – Disable incoming calls during an active call.; 1 – Enable incoming calls during an active call.

%ENABLE_SERVER_REDIAL%

0

0 (default) – Disables the option to redial the last number.; 1 – Enables the phone to redial the last number.

%ENABLE_SHARED_REJECT_SOFTKEY%

1

For shared line calls on the BroadWorks server.; 0 (default) – The Reject soft key does not display.; 1 – The phone displays a Reject soft key to reject an incoming call to a shared line.

%ENABLE_SIM_RING%

0

0 (default) – Disables and does not display the Simultaneous Ring Personal feature menu on the phone.; 1 – Enables the Simultaneous Ring Personal feature menu on the phone.

%ENABLE_SKEY_1%

0

"0 (default) – The x soft key is disabled.; 1 – The x soft key is enabled.; "

%ENABLE_SKEY_2%

0

0 (default) – The x soft key is disabled.; 1 – The x soft key is enabled.;

%ENABLE_SKEY_3%

0

0 (default) – The x soft key is disabled.; 1 – The x soft key is enabled.;

%ENABLE_SKEY_4%

0

0 (default) – The x soft key is disabled.; 1 – The x soft key is enabled.;

%ENABLE_SPLIT_SOFTKEY%

1

Enable to display the Split softkey. The Split softkey allows you to split conference calls into individual calls.; 1 (default) – Enabled; 0 – Disabled

%ENABLE_STATUS_SOFTKEY%

0

Enable to display the MyStatus softkey. The pres.idleSoftKeys parameter must be set to 1.; 1 (default) – Enabled; 0 – Disabled

%ENABLE_UCONE%

0

0 (default) – Disables the BroadSoft UC-One feature.; 1 – Enables the BroadSoft UC-One feature.

%ENABLE_UCONE%

0

Specifies to enable or disable XMPP presence.; 0 (Default); 1

%ENABLE_URL_DIALING%

0

1 (default) – URL/name dialing is available from private lines, and unknown callers are identified on the display by their phone’s IP address.; 0 – URL/name dialing is not available.;

%ENABLE_URL_DIALING%

0

1 (default) – Enable dialing by URL for SIP registrations.; 0 – Disable dialing by URL for SIP registrations.

%ENABLE_VMAIL_SOFTKEY%

1XX, 2xx, 5xx, 6xx: 1; 3xx, 4xx : 0

Enable to display the Vmail softkey.; 1 (default) – Enabled; 0 – Disabled

%ENABLE_VOLATILE_MEMORY%

0

0 (default) – The phone uses non-volatile memory for the local contact directory.; 1 – Enables the use of volatile memory for the local contact directory.

%ENTERPRISE_DIRECTORY%

0

0 (default) – Disables Enterprise Directory.; 1 – Enables Enterprise Directory.

%EXCHANGE_ALERT_TONE_PATTERN%

silent

positiveConfirm (default) – Set the tone pattern of the reminder alerts using any tone specified by se.pat.*.

%EXCHANGE_ALERT_TONE_VOLUME%

10

10 (default) – Set the volume level of reminder alert tones.; 0 – 17

%EXCHANGE_AUTODISCOVER%

0

If you configure exchange.server.url and set this parameter to 1, preference is given to the value of exchange.server.url .; 1 (default) – Lync Base Profile; 0 (default) – Generic Base Profile; 1 – Exchange autodiscovery is enabled and the phone automatically discovers the Exchange server using the email address or SIP URI information.; 0 – Exchange autodiscovery is disabled on the phone and you must manually configure the Exchange server address.

%EXCHANGE_CAL%

0

1 (default) – The calendaring feature is enabled.; 0 – The calendaring feature is disabled.; You must enable this parameter if you also enable feature.exchangeCallLog.enabled.; If you disable feature.exchangeCalendar.enabled, also disable feature.exchangeCallLog.enabled to ensure call log functionality.

%EXCHANGE_PARSE_OPTION%

Location

Select a meeting invite field to fetch a VMR or meeting number from.; Location (default); All; LocationAndSubject; Description

%EXCHANGE_PHONE_PATTERN%

NULL (default); string; The pattern used to identify phone numbers in meeting descriptions, where "x" is a digit and "|" separates alternative patterns (for example, xxx-xxx-xxxx|604.xxx.xxxx).

%EXCHANGE_REMINDER%

0

1 (default) – Meeting reminders are enabled.; 0 – Meeting reminders are disabled.

%EXCHANGE_REMINDER_INTERVAL%

300

300 seconds (default); 60 – 900 seconds; Set the interval at which phones display reminder messages.

%EXCHANGE_REMINDER_TYPE%

2

Customize the calendar reminder and tone.; 2 (default) – The reminder is always audible and visual.; 1 – The first reminder is audible and visual reminders are silent.; 0 – All reminders are silent.

%EXCHANGE_URL%

The Microsoft Exchange server address.; string; NULL (default)

%EXCHANGE_USE_OFFICEHOURS%

0

1 (default) – Enable audible calendar alerts during business hours.; 0 – Disable audible calendar alerts.

%EXEC_ASSISTANT_INDEX%

1

The registered line assigned to the executive or assistant for the BroadSoft Executive-Assistant feature.; 1 (default) to 255 – The registered line for the Executive or Assistant.

%EXEC_ASSISTANT_ROLE%

ExecutiveRole

ExecutiveRole (default) – Sets the registered line as an Executive line.; AssistantRole – Sets the registered line as an Assistant line.

%EXEC_ASSISTANT_SIMPLIFIED_ASSISTANT%

0

0 (default) – Displays the Pick Call and Barge-in soft keys in the Assistants menu on the phone.; 1 – Removes the Pick Call and Barge-in soft keys from the Assistants menu on the phone.

%EXEC_ASSISTANT_SIMPLIFIED_EXEC%

0

0 (default) – Displays the Pick Call and Barge-in soft keys in the Executive menu on the phone.; 1 – Removes the Pick Call and Barge-in soft keys from the Executive menu on the phone.

%FEATURE_SYNC_CF%

1

0 (default) – The server-based call forwarding is disabled.; 1 – server based call forwarding is enabled.

%FEATURE_SYNC_DND%

1

0 (default) – server-based do-not-disturb (DND) is disabled.; 1 – server-based DND is enabled and the call server has control of DND.

%FIRMWARE_VERSION%

Version of Firmware to upgrade/Downgrade the phone to

%G711A%

7

Use the following parameters to specify audio codec priority on your phones.; Permitted values to set audio codec priority are 1 – 27; A value of 1 is the highest priority, 27 the lowest.; If 0 or Null, the codec is disabled.; If a phone does not support a codec, the phone treats the value as 0, does not offer or accept calls using that codec, and continues to the codec next in priority. For example, using the default values, the VVX 310 doesn’t support G.722.1C or G.719 and uses G.722.1 as the next highest-priority codec.;

%G711MU%

6

Use the following parameters to specify audio codec priority on your phones.; Permitted values to set audio codec priority are 1 – 27; A value of 1 is the highest priority, 27 the lowest.; If 0 or Null, the codec is disabled.; If a phone does not support a codec, the phone treats the value as 0, does not offer or accept calls using that codec, and continues to the codec next in priority. For example, using the default values, the VVX 310 doesn’t support G.722.1C or G.719 and uses G.722.1 as the next highest-priority codec.;

%G722%

4

"Use the following parameters to specify audio codec priority on your phones.; Permitted values to set audio codec priority are 1 – 27; A value of 1 is the highest priority, 27 the lowest.; If 0 or Null, the codec is disabled.; If a phone does not support a codec, the phone treats the value as 0, does not offer or accept calls using that codec, and continues to the codec next in priority. For example, using the default values, the VVX 310 doesn’t support G.722.1C or G.719 and uses G.722.1 as the next highest-priority codec.; "

%G729%

8

"Use the following parameters to specify audio codec priority on your phones.; Permitted values to set audio codec priority are 1 – 27; A value of 1 is the highest priority, 27 the lowest.; If 0 or Null, the codec is disabled.; If a phone does not support a codec, the phone treats the value as 0, does not offer or accept calls using that codec, and continues to the codec next in priority. For example, using the default values, the VVX 310 doesn’t support G.722.1C or G.719 and uses G.722.1 as the next highest-priority codec.; "

%GMT_OFFSET%

-18000

Set the GMT offset, in seconds, to use for daylight saving time, corresponding to -12 to +13 hours.; -43200 to 46800

%GMT_OFFSET%

-18000

Specifies the offset in seconds of the local time zone from GMT.; 0 (Default) – GMT; 3600 seconds = 1 hour; -3600 seconds = -1 hour; Positive or negative integer

%GROUP_DIRECTORY%

1

0 (default) – Disables Group Directory.; 1 – Enables Group Directory.

%GUI_INVALIDATTEMPTS%

5

The Number of invalid login attempts before lockout

%GUI_INVALIDATTEMPTS_DURATION%

60

The Lockout Duration in seconds

%GUIPASSWORD%

(contact support)

Set the phone user’s local password. The minimum length is defined by sec.pwd.length.user.; String (32 character max)

%GUIPASSWORD%

(contact support)

Set the phone’s local administrative password. The minimum length is defined by sec.pwd.length.admin.; String (32 character max)

%H263%

0

5 (default); 0 – 8

%H264%

0

4 (default); 0 – 8

%HEADSET_MEMORY%

0

Sets the preferred audio mode of handsfree or headset.; 0 (Default) – Handsfree mode is used by default instead of the handset.; 1 – Headset is used as the preferred audio mode after the headset key is pressed for the first time, until the headset key is pressed again.

%HEADSET_MODE%

2

Electronic Hookswitch (EHS) mode for the phone’s analog headset jack.; 2 (default) – Plantronics EHS-compatible headset is attached.; 0 – No EHS-compatible headset is attached.; 1 – Jabra EHS-compatible headset is attached.; 3 – Sennheiser EHS-compatible headset is attached.

%LDAP_BGSYNC%

0

Determine if background downloading from the LDAP server is enabled or disabled.; 0 (default) – Disabled; 1 – Enabled

%LDAP_BGSYNC_PERIOD%

86400

Set the time in seconds the corporate directory cache is refreshed after the corporate directory feature has not been used for the specified period of time.; 86400 (default); 3600 to 604800

%LDAP_CS%

128

Set the maximum number of entries that can be cached locally on the phone.; 128 (default); 32 to 256

%LDAP_DN%

Enter the base domain name, which is the starting point for making queries on the LDAP server.; Null (default); UTF-8 encoding string

%LDAP_ENABLE%

0

0 (default) – The corporate directory feature is disabled and the icon is hidden.; 1 (default) – The corporate directory is enabled and the icon shows.

%LDAP_FILTER%

objectclass=person

Enter the predefined filter string for search queries.; (objectclass=person) (default); UTF-8 encoding string

%LDAP_PASSWORD%

(contact support)

Enter the password used to authenticate to the LDAP server.; UTF-8 encoding string

%LDAP_PORT%

389

Enter the port that connects to the server if a full URL is not provided.; 389 (default for TCP); 636 (default for TLS); 0; Null; 1 to 65535

%LDAP_PROT%

TCP

Specify whether a TCP or TLS connection is made with the server if a full URL is not provided.; TCP (default); TLS; Null

%LDAP_PS%

65

Set the maximum number of entries requested from the corporate directory server with each query.; 64 (default); 8 to 64;

%LDAP_SCOPE%

base

sub (default) – a recursive search of all levels below the base domain name is performed.; one – a search of one level below the base domain name is performed.; base – a search at the base domain name level is performed.

%LDAP_SERVER%

Set the IP address or hostname of the LDAP server interface to the corporate directory.; Null (default); IP address; Hostname; FQDN

%LDAP_USER%

Enter the user name used to authenticate to the LDAP server.; Null (default); UTF-8 encoding string

%LDAP_VLV_ENABLE%

0

Determine whether virtual view list (VLV) queries are enabled and can be made if the LDAP server supports VLV.; 0 (default); 1

%LDAP_VLV_SO%

Enter the list of parameters, in exact order, for the LDAP server to use when indexing. For example: sn, givenName, telephoneNumber .; Null (default); list of parameters

%LDAP_VPER%

0

0 (default) – The corporate directory search filters and browsing position are reset each time the user accesses the corporate directory.; 1 – The search filters and browsing position from the previous session are displayed each time the user accesses the corporate directory.;

%LDAP_x_FILTER%

Set the filter string for this parameter, which is edited when searching.; Null (default); UTF-8 encoding string

%LDAP_x_LABEL%

Enter the label that shows when data is displayed.; Null (default); UTF-8 encoding string

%LDAP_x_NAME%

Enter the name of the parameter to match on the server. Each name must be unique; however, a global address book entry can have multiple parameters with the same name. You can configure up to eight parameters (x = 1 to 8).; Null (default); UTF-8 encoding string

%LDAP_x_SEARCH%

0

Determine whether quick search on parameter x (if x is 2 or more) is enabled or disabled.; 0 (default) – Disabled; 1 – Enabled

%LDAP_x_STICKY%

0

Sets whether the filter string criteria for attribute x is reset or retained after a phone reboot. If you set an attribute to be sticky (set this parameter to 1), a ‘*’ displays before the label of the attribute on the phone.; 0 (default) ‒ Reset after a phone reboot.; 1 ‒ Retain after a phone reboot.

%LDAP_x_TYPE%

last_name

Define how x is interpreted by the phone. Entries can have multiple parameters of the same type. If the user saves the entry to the local contact directory on the phone, first_name, last_name, and phone_number are copied. The user can place a call to the phone_number and SIP_address from the global address book directory.; first_name; last_name (default); phone_number; SIP_address; H323_address URL; other

%LINE_x_INDEX%

Equal to the line number, EX Line 10 is Index 10

0 (default) – The index value for BLF or presence.; 0- 9999

%LINE_x_TYPE%

Lines 1-12: Line; Lines 13-84: Speed Dial

Specify the line key category.; Any (default); Unassigned (default); Line; BLF; EFK; SpeedDial; Presence

%LINEKEYS_x%

1

Specify the number of line keys to use for a single registration. The maximum number of line keys you can use per registration depends on your phone model.; 1 (default); 1 to max

%LLDP%

1

0 – The phone doesn’t attempt to determine its VLAN ID.; 1 – The phone attempts to determine its VLAN ID and negotiate power through LLDP.;

%MINIMUM_RINGER_VOLUME%

16

Configure the minimum ringer volume. This parameter defines how many volume steps are accessible below the maximum level by the user.; 16 (Default) – Full 16 steps of volume range are accessible.; 0 – Ring volume is not adjustable by the user and the phone uses maximum ring volume.; Example: Upon bootup, the volume is set to ½ the number of configured steps below the maximum (16). If the parameter is set to 8 on bootup, the ringer volume is set to 4 steps below maximum.

%NETWORK_CONFERENCE_URI%

Null (default) – Conferences are set up on the phone locally.; String 128 max characters – Enter a conference address. Conferences are set up by the server using the conferencing agent specified by this address. Acceptable values depend on the conferencing server implementation policy.

%NTP_OVERRIDE_DHCP%

0

0 (Default) – DHCP values for the SNTP server address are used.; 1 – SNTP parameters override the DHCP values.

%NTP_OVERRIDE_DHCP%

0

0 (Default) – The DHCP values for the GMT offset are used.; 1 – The SNTP values for the GMT offset are used.

%OFFHOOKLINEVIEW%

0

Set the default screen that appears when the phone goes off-hook.; 0 (Default) – Dialing screen; 1 – Line screen

%ONE_TOUCH_VMAIL%

0

0 (default) – Generic Base Profile; 0 (default) – The phone displays a summary page with message counts.; 1 – You can call voicemail services directly from the phone, if available on the call server, without displaying the voicemail summary.

%PC_PORT_MODE%

0

Set the PC port mode that sets the network speed over Ethernet.; -1 – Disables the PC port; 0 – Auto (default); 1 – 10HD; 2 – 10FD; 3 – 100HD; 4 – 100FD; 5 – 1000FD; HD means half-duplex and FD means full duplex.; Change causes system to restart or reboot.

%PC_PORT_SET%

1

%PERSONAL_DIRECTORY%

1

0 (default) – Disables Personal Directory.; 1 – Enables Personal Directory.

%PHONELOCK_1_AUTH_DESC%

The name or description of an authorized number.; Null (default); String; Up to five (x=1 to 5) authorized contacts that a user can call while their phone is locked. Each contact needs a description to display on the screen, and a phone number or address value for the phone to dial.

%PHONELOCK_1_AUTH_VALUE%

The number or address for an authorized contact.; Null (default); String; Up to five (x=1 to 5) authorized contacts that a user can call while their phone is locked. Each contact needs a description to display on the screen, and a phone number or address value for the phone to dial.

%PHONELOCK_2_AUTH_DESC%

The name or description of an authorized number.; Null (default); String; Up to five (x=1 to 5) authorized contacts that a user can call while their phone is locked. Each contact needs a description to display on the screen, and a phone number or address value for the phone to dial.

%PHONELOCK_2_AUTH_VALUE%

The number or address for an authorized contact.; Null (default); String; Up to five (x=1 to 5) authorized contacts that a user can call while their phone is locked. Each contact needs a description to display on the screen, and a phone number or address value for the phone to dial.

%PROV_ENCODINGMODE%

(contact support)

The default encoding mode for the text in the Password field on the User Login screen.; Alphanumeric

%PROV_ENCODINGMODE%

(contact support)

prov.login.userId.encodingMode; The default encoding mode for the text in the User ID field on User Login screen.; Alphanumeric;

%REG_EXPIRES_TIMER%

120

The phone’s requested registration period in seconds.; The period negotiated with the server may be different. The phone attempts to re-register at the beginning of the overlap period.; 3600 – (default); positive integer, minimum 10

%REMOTE_ANSWERED_ADDTOLIST%

0

Applies to calls on that are answered remotely.; 0 (default) – Calls answered from the remote phone are not added to the local receive call list.; 1 – Calls answered from the remote phone are added to the local

%REQUEST_AUTH%

voIpProt.SIP.requestValidation.x.method; Null (default) – No validation is made.; Source – Ensure request is received from an IP address of a server belonging to the set of target registration servers.; digest – Challenge requests with digest authentication using the local credentials for the associated registration (line).; both or all – Apply both of the above methods.

%RINGBACK_FREQ1%

4400

%RINGBACK_FREQ2%

480

%RINGBACK_LEVEL1%

-20

%RINGBACK_LEVEL2%

-20

%RINGBACK_OFFDUR%

4000

%RINGBACK_ONDUR%

1000

%RINGBACK_REPEAT%

0

%RINGTONE_TYPE%

The ringer to be used for calls received by this registration. The default is the first non-silent ringer.; If you use the configuration parameters ringer13 and ringer14 on a single registered line, the phone plays SystemRing.wav.; default (default); ringer1 to ringer24

%RINGTONE_URL%

Specify a path or URL for the phone to download a custom audio file.; Null (default)—The phone uses a built-in file.; Path Name —During startup, the phone attempts to download the file at the specified path in the provisioning server.; URL— During startup, the phone attempts to download the file from the specified URL on the Internet. Must be a RFC 1738-compliant URL to an HTTP, FTP, or TFTP wave file resource.; If using TFTP, the URL must be in the following format: tftp:///[pathname] . For example: tftp://somehost.example.com/sounds/example.wav .; To use a welcome sound, enable the parameter up.welcomeSoundEnabled and specify a file in saf.x . The default UC Software welcome sound file is Welcome.wav .

%RINGTONEx_TYPE%

The ringer to be used for calls received by this registration. The default is the first non-silent ringer.; If you use the configuration parameters ringer13 and ringer14 on a single registered line, the phone plays SystemRing.wav.; default (default); ringer1 to ringer24

%SAVE_VOLUME%

1

Specifies whether the handset’s volume level persists and stays at the same level between calls.; 0 (default) – The handset volume automatically resets to a nominal level after each call.; 1 – The volume for each call is the same as the previous call.

%SAVE_VOLUME_HEADSET%

1

0 (default) – The analog headset volume does not persist between calls and is reset each new call.; 1 – The analog headset volume at the end of a call persists between calls.

%SAVE_VOLUME_SPEAKER%

1

Specify if the speakerphone volume persists between calls.; 1 (default) – The speakerphone volume at the end of a call persists between calls.; 0 – The speakerphone volume does not persist between calls and resets to a nominal level each new call.

%SAVE_VOLUME_USB%

0

0 (default) – The USB headset volume does not persist between calls and resets to a nominal level each new call.; 1 – The USB headset volume at the end of a call persists between calls.

%SBC_ADDRESS%

us-sbc.14ip.net; eu1-sbc.14ip.net

SBC Proxy Address

%SBC_ADDRESS%

us-sbc.14ip.net

The IP address or hostname of the SIP server to which the phone sends all requests.; Null (default); IP address or hostname

%SHARED_SHAREDDISABLED%

0

1 (default) – Disables call diversion features on shared lines.; 0 – Enables call diversion features on shared lines.

%SIP_EXPIRES_OVERLAP%

60

The number of seconds before the expiration time returned by server x at which the phone should try to re-register.; The phone tries to re-register at half the expiration time returned by the server if the server value is less than the configured overlap value.; 60 (default); 5 to 65535

%SIP_LOCAL_PORT%

5060

Local SIP Port

%SIP_PORT%

0

Outbound Proxy SIP port

%SIP_PORT%

0

The port of the SIP server to which the phone sends all requests.; 0 – (default); 1 to 65535;

%SKEY_1_ACTION%

Controls the action or function for the custom soft key x.; Null (default); macro action string, 2048 characters; This value uses the same macro action string syntax as an Enhanced Feature Key.

%SKEY_1_ACTIVE%

0

0 (default) – Does not display the soft key x during an active call.; 1 – Displays the soft key x during an active call.

%SKEY_1_ALERTING%

0 (default) – Does not display the soft key x in an alerting state during an active call.; 1 – Displays the soft key x in an alerting state during an active call.

%SKEY_1_DIALTONE%

0 (default) – Does not display the soft key in the dial tone state during an active call.; 1 – Displays the soft key x in the dial tone state during an active call.

%SKEY_1_HOLD%

0 (default) – Does not display the soft key x in the hold state during an active call.; 1 – Displays the soft key x in the hold state during an active call

%SKEY_1_IDLE%

0 (default) – Does not display the soft key x in the idle state during an active call.; 1 – Displays the soft key x in the idle state during an active call.

%SKEY_1_INSERT%

0

0 (default) – The phone places the soft key in the first available position.; 0 to 10 – The phone places the soft key in the corresponding position and moves the following soft keys by one position to the right.; For example, if the soft key is set to 3, the soft key is displayed in the third position from the left. If the soft key already exists in the third position, it is moved to fourth position and the following soft keys are moved to right by one space.; If softkey.x.precede is configured, this value is ignored. If the insert location is greater than the number of soft keys, the key is positioned last after the other soft keys.

%SKEY_1_LABEL%

The text displayed on the soft key label. If Null, the label is determined as follows:; If the soft key performs an Enhanced Feature Key macro action, the label of the macro defined using efk.efklist is used.; If the soft key calls a speed dial, the label of the speed dial contact is used.; If the soft key performs chained actions, the label of the first action is used.; If the soft key label is Null and none of the preceding criteria are matched, the label is blank.; Null (default); String; Note: The maximum number of characters for this parameter value is 15; however, the maximum number of characters that a phone can display on its user interface varies by phone model and by the width of the characters used. Parameter values that exceed the phone’s maximum display length are truncated by ellipses (…). The phone truncates the beginning of numerical labels (for example, …4567) and truncates the end of alphabetical labels (for example, Abcd…).

%SKEY_1_PARK%

0 (default) – Does not display the soft key x in the parked state during an active call.; 1 – Displays the soft key x in the parked state during an active call.

%SKEY_1_PRECEDE%

0 (default) – The phone locates the soft key in the first available position from left.; 1 – The phone locates the soft key before the default soft key position.

%SKEY_1_PROCEEDING%

0 (default) – Does not display the soft key x in the proceeding state during an active call.; 1 – Displays the soft key x in the proceeding state during an active call.

%SKEY_1_SETUP%

0 (default) – Does not display the soft key x in the setup state during an active call.; 1 – Displays the soft key x in the setup state during an active call.

%SKEY_2_ACTION%

Controls the action or function for the custom soft key x.; Null (default); macro action string, 2048 characters; This value uses the same macro action string syntax as an Enhanced Feature Key.

%SKEY_2_ACTIVE%

0

0 (default) – Does not display the soft key x during an active call.; 1 – Displays the soft key x during an active call.

%SKEY_2_ALERTING%

0 (default) – Does not display the soft key x in an alerting state during an active call.; 1 – Displays the soft key x in an alerting state during an active call.

%SKEY_2_DIALTONE%

0 (default) – Does not display the soft key in the dial tone state during an active call.; 1 – Displays the soft key x in the dial tone state during an active call.

%SKEY_2_HOLD%

0 (default) – Does not display the soft key x in the hold state during an active call.; 1 – Displays the soft key x in the hold state during an active call

%SKEY_2_IDLE%

0 (default) – Does not display the soft key x in the idle state during an active call.; 1 – Displays the soft key x in the idle state during an active call.

%SKEY_2_INSERT%

0

0 (default) – The phone places the soft key in the first available position.; 0 to 10 – The phone places the soft key in the corresponding position and moves the following soft keys by one position to the right.; For example, if the soft key is set to 3, the soft key is displayed in the third position from the left. If the soft key already exists in the third position, it is moved to fourth position and the following soft keys are moved to right by one space.; If softkey.x.precede is configured, this value is ignored. If the insert location is greater than the number of soft keys, the key is positioned last after the other soft keys.

%SKEY_2_LABEL%

The text displayed on the soft key label. If Null, the label is determined as follows:; If the soft key performs an Enhanced Feature Key macro action, the label of the macro defined using efk.efklist is used.; If the soft key calls a speed dial, the label of the speed dial contact is used.; If the soft key performs chained actions, the label of the first action is used.; If the soft key label is Null and none of the preceding criteria are matched, the label is blank.; Null (default); String; Note: The maximum number of characters for this parameter value is 15; however, the maximum number of characters that a phone can display on its user interface varies by phone model and by the width of the characters used. Parameter values that exceed the phone’s maximum display length are truncated by ellipses (…). The phone truncates the beginning of numerical labels (for example, …4567) and truncates the end of alphabetical labels (for example, Abcd…).

%SKEY_2_PARK%

0 (default) – Does not display the soft key x in the parked state during an active call.; 1 – Displays the soft key x in the parked state during an active call.

%SKEY_2_PRECEDE%

0 (default) – The phone locates the soft key in the first available position from left.; 1 – The phone locates the soft key before the default soft key position.

%SKEY_2_PROCEEDING%

0 (default) – Does not display the soft key x in the proceeding state during an active call.; 1 – Displays the soft key x in the proceeding state during an active call.

%SKEY_2_SETUP%

0 (default) – Does not display the soft key x in the setup state during an active call.; 1 – Displays the soft key x in the setup state during an active call.

%SKEY_3_ACTION%

Controls the action or function for the custom soft key x.; Null (default); macro action string, 2048 characters; This value uses the same macro action string syntax as an Enhanced Feature Key.

%SKEY_3_ACTIVE%

0

0 (default) – Does not display the soft key x during an active call.; 1 – Displays the soft key x during an active call.

%SKEY_3_ALERTING%

0 (default) – Does not display the soft key x in an alerting state during an active call.; 1 – Displays the soft key x in an alerting state during an active call.

%SKEY_3_DIALTONE%

0 (default) – Does not display the soft key in the dial tone state during an active call.; 1 – Displays the soft key x in the dial tone state during an active call.

%SKEY_3_HOLD%

0 (default) – Does not display the soft key x in the hold state during an active call.; 1 – Displays the soft key x in the hold state during an active call

%SKEY_3_IDLE%

0 (default) – Does not display the soft key x in the idle state during an active call.; 1 – Displays the soft key x in the idle state during an active call.

%SKEY_3_INSERT%

0

0 (default) – The phone places the soft key in the first available position.; 0 to 10 – The phone places the soft key in the corresponding position and moves the following soft keys by one position to the right.; For example, if the soft key is set to 3, the soft key is displayed in the third position from the left. If the soft key already exists in the third position, it is moved to fourth position and the following soft keys are moved to right by one space.; If softkey.x.precede is configured, this value is ignored. If the insert location is greater than the number of soft keys, the key is positioned last after the other soft keys.

%SKEY_3_LABEL%

The text displayed on the soft key label. If Null, the label is determined as follows:; If the soft key performs an Enhanced Feature Key macro action, the label of the macro defined using efk.efklist is used.; If the soft key calls a speed dial, the label of the speed dial contact is used.; If the soft key performs chained actions, the label of the first action is used.; If the soft key label is Null and none of the preceding criteria are matched, the label is blank.; Null (default); String; Note: The maximum number of characters for this parameter value is 15; however, the maximum number of characters that a phone can display on its user interface varies by phone model and by the width of the characters used. Parameter values that exceed the phone’s maximum display length are truncated by ellipses (…). The phone truncates the beginning of numerical labels (for example, …4567) and truncates the end of alphabetical labels (for example, Abcd…).

%SKEY_3_PARK%

0 (default) – Does not display the soft key x in the parked state during an active call.; 1 – Displays the soft key x in the parked state during an active call.

%SKEY_3_PRECEDE%

0 (default) – The phone locates the soft key in the first available position from left.; 1 – The phone locates the soft key before the default soft key position.

%SKEY_3_PROCEEDING%

0 (default) – Does not display the soft key x in the proceeding state during an active call.; 1 – Displays the soft key x in the proceeding state during an active call.

%SKEY_3_SETUP%

0 (default) – Does not display the soft key x in the setup state during an active call.; 1 – Displays the soft key x in the setup state during an active call.

%SKEY_4_ACTION%

Controls the action or function for the custom soft key x.; Null (default); macro action string, 2048 characters; This value uses the same macro action string syntax as an Enhanced Feature Key.

%SKEY_4_ACTIVE%

0

0 (default) – Does not display the soft key x during an active call.; 1 – Displays the soft key x during an active call.

%SKEY_4_ALERTING%

0 (default) – Does not display the soft key x in an alerting state during an active call.; 1 – Displays the soft key x in an alerting state during an active call.

%SKEY_4_DIALTONE%

0 (default) – Does not display the soft key in the dial tone state during an active call.; 1 – Displays the soft key x in the dial tone state during an active call.

%SKEY_4_HOLD%

0 (default) – Does not display the soft key x in the hold state during an active call.; 1 – Displays the soft key x in the hold state during an active call

%SKEY_4_IDLE%

0 (default) – Does not display the soft key x in the idle state during an active call.; 1 – Displays the soft key x in the idle state during an active call.

%SKEY_4_INSERT%

0

0 (default) – The phone places the soft key in the first available position.; 0 to 10 – The phone places the soft key in the corresponding position and moves the following soft keys by one position to the right.; For example, if the soft key is set to 3, the soft key is displayed in the third position from the left. If the soft key already exists in the third position, it is moved to fourth position and the following soft keys are moved to right by one space.; If softkey.x.precede is configured, this value is ignored. If the insert location is greater than the number of soft keys, the key is positioned last after the other soft keys.

%SKEY_4_LABEL%

The text displayed on the soft key label. If Null, the label is determined as follows:; If the soft key performs an Enhanced Feature Key macro action, the label of the macro defined using efk.efklist is used.; If the soft key calls a speed dial, the label of the speed dial contact is used.; If the soft key performs chained actions, the label of the first action is used.; If the soft key label is Null and none of the preceding criteria are matched, the label is blank.; Null (default); String; Note: The maximum number of characters for this parameter value is 15; however, the maximum number of characters that a phone can display on its user interface varies by phone model and by the width of the characters used. Parameter values that exceed the phone’s maximum display length are truncated by ellipses (…). The phone truncates the beginning of numerical labels (for example, …4567) and truncates the end of alphabetical labels (for example, Abcd…).

%SKEY_4_PARK%

0 (default) – Does not display the soft key x in the parked state during an active call.; 1 – Displays the soft key x in the parked state during an active call.

%SKEY_4_PRECEDE%

0 (default) – The phone locates the soft key in the first available position from left.; 1 – The phone locates the soft key before the default soft key position.

%SKEY_4_PROCEEDING%

0 (default) – Does not display the soft key x in the proceeding state during an active call.; 1 – Displays the soft key x in the proceeding state during an active call.

%SKEY_4_SETUP%

0 (default) – Does not display the soft key x in the setup state during an active call.; 1 – Displays the soft key x in the setup state during an active call.

%SNTP_ALT_SERVER%

pool.ntp.org

Enter the SNTP server where the phone obtains the current time.; IP address; Domain name string

%SNTP_SERVER%

pool.ntp.org

Specifies the SNTP server address.; NULL (default); Valid hostname or IP address.

%TIME_24HR%

0

1 (default) – Displays the time in 24-hour clock mode.; 0 – Displays the time in 12-hour clock mode.

%TRANSFER_TYPE%

Consultative

Blind —Users complete a call transfer without speaking with the other party first.; Consultative —Users speak with the other party before completing the transfer.

%TRANSPORT%

DNSnaptr

Transport protocol

%TRANSPORT%

DNSnaptr

The transport method the phone uses to communicate with the SIP server.; DNSnaptr (default) – If reg.x.server.y.address is a hostname and reg.x.server.y.port is 0 or Null, do NAPTR then SRV look-ups to try to discover the transport, ports and servers, as per RFC 3263. If reg.x.server.y.address is an IP address, or a port is given, then UDP is used.

%VLAN_ID%

Set the phone’s 802.1Q VLAN identifier.; Null – No VLAN tagging.; 0 to 4094

%VLAN_SET%
